Model No
YDM7116A
YDM7116A (5 ways of access)
$999.00
(Price is inclusive of taxes)
In stock
Product Key Features
- Card Key
- Fingerprint
- Mechanical Key
- PIN Code
- Work with App
- Remote access
Product Description
SGAA_YDM-M761B-Y3
Yale YDM7116A provides multiple access solutions - Fingerprint, PIN Code, RFID Card, mobile access via Yale Access APP (optional)* and remote access via Yale Access APP (optional)* .
*Yale Access BLE Module and Yale Connect Bridge (Wifi connection) are required and sold separately.
Technical Details:
*Yale Access BLE Module and Yale Connect Bridge (Wifi connection) are required and sold separately.
Technical Details:
- Mortise lock
- Up to 100 RFID Cards
- Up to 100 different fingerprint
- Up to 100 different PINcodes
- Mechanical Keys: 2 Keys
- Front Body : 40mm ( D) X 68mm (W) X 340mm (H) (w/o lever)
- Back Body : 38mm (D) X 72mm (W) X 344mm (H) (w/o lever)
| Model No | YDM7116A |
|---|---|
| DDL Access Type | Finger Print / PIN / Card |
| Door Thickness Range | 40mm - 80mm |
| Credential Type | Mifare Classic 4K |
| Bolt Material | Stainless Steel |
| Electro-mechanical | Yes |
| Battery type | AA |
| Residential | Yes |
| Door Material | Timber |
| Warranty / Guarantee | 2 Years |
| Battery life | 3000 Cycles |
| Audible Indicator | Yes |
| Body / Case Material | AL Die-casting |
| Backset | 70mm |
| Audit trails | Yes |
| RMC | Yes |
| Network connected | Yes |
| Break in/ tamper alarm | Yes |
| No. of Registered cards | 100 |
| No. of Registered Fingerprint | 100 |
| Fake PIN | Yes |
| Lock Type | Mortise |
| Colour | Black |
